How to manage Seuic handheld devices using Hexnode MDM

Jayden Traoré

May 21, 2020

29 min read

Jiangsu SEUIC Technology Co., Ltd is a Chinese manufacturer of handhelds, rugged devices, RFID readers, barcode scanners in logistics and similar industries, established in 2002.

Seuic has always been focused on the research and development of RFID and barcode scanners for frontline workers in enterprises.

Hexnode’s partnership with Seuic Mobile enables our users to leverage Seuic’s API for device management via OEMConfig which extends the management capabilities beyond our native features.

Note:

Seuic mobile’s OEMConfig app is called the Seuic OEMConfig.

 The main list of Seuic device include:

  • Seuic CRUISE 1
  • Seuic New AUTOID 9
  • Seuic New AUTOID Pad
  • Seuic AUTOID Q7(Cold)
  • Seuic AUTOID Q7(Grip)
  • Seuic AUTOID 9U

 Besides these, they also specialize in barcode scanners, RFID readers, and proprietary OS devices.

How to manage Seuic handheld devices using Hexnode’s native device management feature?

Hexnode’s Android device management capabilities can be leveraged to manage Seuic devices directly.

Enrollment

Hexnode MDM provides a wide variety of enrollment methods for Android devices, you are free to choose the ones that are convenient for your business model.

No authentication enrollment: It is the fastest enrollment method available. It only requires the server name. No authentication and no enrollment credentials are needed. All devices enrolled this way are assigned to a default user.

Email/SMS enrollment: Here the enrollment credentials are sent to the users via email or SMS. These credentials have to be entered to complete the enrollment process.

Self-Enrollment: This method allows the users to enroll their devices via Azure Active Directory, Active Directory, or Google user credentials. For other users, the admin may create a default user and a dedicated password manually or assign a common password or individual passwords for the users and sends it to them as a bulk mail. The enrollment process is pretty much the same.

QR code enrollment: In certain scenarios, it is difficult to enroll devices with credentials like username, password and portal name. Hexnode MDM lets you enroll devices easily by scanning a QR code.

ROM enrollment: If your enterprise has a collaboration with Seuic you can flash a custom ROM to the Android Device with Hexnode MDM as a system app.

Android Enterprise Enrollment: Previously known as Android for work, it is currently the main enrollment method for android devices. It creates a separate work container on the devices. The separation of corporate and personal data is necessary if the devices are BYOD (Bring your own device) or COPE (Corporate owned personally enabled). The Hexnode for work app is used for Android enterprise enrollment. AFW# and ADB methods are also used for Android Enterprise Enrollment.

Zero-touch enrollment: This is ideal for bulk deployment of devices. The devices need to be purchased from a Seuic zero-touch reseller partner. It is ideal for corporate-owned devices as it is a one-time configuration process. Hence, the devices come pre-configured out of the box. This also eliminates the need for user intervention in setting up the devices.

Management

Hexnode provides the A – Z in device management. The main management features for Seuic devices include:

Device info and monitoring: Android Device monitoring features include device summary which provides a summary of the hardware info like model, type, OS version, root info, battery level, memory level. It also provides enrollment details (last checked-in, last scan, device id, enrollment date, and status).

Location information is also available with map support to pinpoint the exact location the device was last active at. Compliance to policies and restrictions, the number of apps currently on the device, activity status, the number of policies currently associated, kiosk status, and last checked-in time can also be viewed from the Manage section.

The device info section includes the device model name, manufacturer (Seuic), Serial no, UID, etc. Network Info section includes the phone number of the SIM cards on the device, IMEI numbers of the device, roaming status, carrier details, etc.

Application, Policies, Security sections under manage has the full list of associated policies and applications.

Actions: A large list of actions are available for Seuic devices. Scan option is used for scanning the devices to refresh the data and listing the current device status, it can also be used to scan the device location. Lock, wipe, remote ring, enabling lost mode actions are useful in cases of emergency (lost or stolen devices with valuable corporate data).

Changing the device owner, installing and uninstalling applications, associating configured policies, OS updates, changing the friendly name for the device, changing ringtone, importing contacts to device can all be done remotely via the actions tab in device management.

Enabling and disabling kiosk mode can be achieved at the click of a button. Broadcasting notifications and messages to the selected devices are very popular among our users.

The action tab also allows the exporting of device details as a pdf file. When you are all done with a device you can disenroll it from the Henoxde MDM portal using the Disenroll device action.

Action History section shows the activity log for the device along with the status of each action and messages related to it.

Remote control and view: The manage tab for Android devices provides the remote device view option. This is achieved via the remote view app which can be remotely installed on any device. It lets you view the user’s device in real-time. This nifty feature lets you monitor the users that require supervision.

The remote control feature is available for Android 5.0+ and Android Enterprise devices. The remote control allows admins to monitor and take control of the device from their PC. It can come in handy when you need to take control of the devices to diagnose and fix problems reported by the users in real-time.

Data Management: The data management section under Manage shows the data usage by the device as a whole and for each app individually.

Total data usage, Mobile data usage, WIFI data usage as a whole, and for each application are listed under this section. The data usage details can be exported as a CSV or PDF from here. The section also has filters to view the usage by dates and periods. A list of apps with blocked data access are also listed here.

Users, devices, and groups: All enrolled devices can be divided into groups for easier monitoring. Similarly, users can also be grouped.

Grouping of devices and users not only allows easier monitoring, it also helps in managing them together via actions and policies. Grouping is highly recommended in cases where the device count is high.

Hexnode MDM also supports dynamic grouping. Dynamic groups keep changing automatically based on certain specified conditions. In dynamic grouping, devices move in and out of the group during the periodic group sync, whereas custom groups maintain devices as a fixed list. The sufficiency of minimal manual effort makes dynamic grouping more desirable than manual grouping.

Restrictions

Device Functionality: Enable or disable device functionality features like camera, USB file transfer, safe mode, lock screen orientation and lock screen timeout.

Network Settings: Provision to forcefully turn the Wi-Fi on and off besides disabling or enabling the feature can be useful to certain enterprise needs.

Enabling or disabling Bluetooth, tethering, a portable wi-fi hotspot, and data roaming can be done.

Synchronization settings: Backing up or restoring data from google drive can be disabled on Android 8.0+ devices in device owner mode.

Advanced device functionality restrictions: Disabling of the device microphone, screen capture, making a call, volume adjustment, and the copying of content between normal and work profiles are available for Seuic devices.

Advanced Display settings: Hiding the device status bar and displaying dialogs/windows are available under this section.

Advanced Connectivity settings: Bluetooth data transfer, android beam, configuring Bluetooth, configuring cell broadcast, configuring cellular network, configuring Wi-Fi, configuring hotspot and tethering, and the ability to reset network settings can be disabled from the Hexnode MDM portal.

Advanced account and application settings: Sending SMS, configuring user credentials, and modifying the user’s Google accounts (add, delete, switch) can be done here.

Installing and uninstalling apps, modifying application settings, app verification before installations, allowing the installation of applications from unknown sources, parent profile app linking, and app runtime permissions can all be enabled or disabled to suit your enterprise’s needs.

Other advanced settings: Factory reset protection can be disabled or bypassed on devices in Android Enterprise device owner mode.

Enabling location sharing, USB debugging, factory reset, reading external connected media, setting up time zone, updating date and time automatically, and configuring VPN can also be done via the Hexnode MDM portal.

All advanced device settings are available only for Android Enterprise devices.

Policies

Password: Secure your Seuic devices with Hexnode’s password policy. Password complexity, password age, password history can be configured for the devices. Added security via auto-lock and device wipe after a set number of failed attempts can also be configured. This method is used to lock the entire device in normal mode. In device owner mode the password policies are only applicable to device owner container and work apps.

For devices running Android 7.0+ enrolled in profile owner mode the work profile alone can be locked with the password policy.

App Management: Mandatory app policy allows you to install applications on the device. In android enterprise mode (as managed google apps), rooted devices, and devices with Hexnode MDM app as a system app, apps can be installed on the device silently. In all other cases, user intervention is required to install applications.

Blacklisting of apps in Android Enterprise devices will cause the device to fall out of compliance if the blacklisted applications are present on the device. In the Profile Owner mode, blacklisted apps will be hidden from the work container. Whitelisting of apps causes all other apps(not whitelisted) to be considered as blacklisted.

App Cataloging is used to create a customized app store on the end user’s device. App configuration and app permissions can be used to manage and configure the applications before pushing them to the devices (Only in Android Enterprise).

Networks: Wi-Fi networks can be pre-configured and associated to the devices so that they can connect automatically to the network without prompting the users to enter passwords. This saves the organization the hassle of sharing the credentials with each employee.

Security: Certificates can be installed on the Seuic devices remotely to ensure higher security. Similarly, OS updates can also be scheduled on devices enrolled in Device Owner mode.

Configurations: Wallpaper for the device home screen is customizable on all devices with Android 4.4 and above from the Hexnode MDM portal.

Mobile Data Management and File Management: The Mobile data management feature on Android 6.0+ devices allow admins to monitor how Wi-Fi and mobile data connection are used. Usage limits can be set up, network connectivity can also be restricted if limits are reached (monthly, daily, etc. on the device as a whole or on apps individually). This can be useful in tracking data hogging applications.

File Management can be used to upload files (videos, audios, images, documents) to a designated space within an enrolled device.

Kiosk Features: In most enterprises, the devices are used to access only a limited set of applications. Single app and multi-app kiosk modes by Hexnode MDM can be used for locking down your devices to only the required applications.

Hexnode also provides the option to run apps in the background as certain apps require access to other apps to function properly. The devices can be turned into Digital signages for advertisements and can be set up as a self-service kiosk. A custom kiosk launcher, kiosk screen savers, website kiosks are just the tip of the iceberg.

Kiosks can also be highly customized by restricting device actions and buttons. Kiosk exit settings and website kiosk settings should be configured as per the requirement to adapt the kiosk to the enterprise’s needs. Hexnode browser lite and Hexnode kiosk browser features can also be modified to control how the website kiosk works.

Seuic handheld devices are commonly used as handhelds, barcode scanners in logistics and industries, hence Hexnode’s extensive kiosk capabilities will compliment it quite nicely.

Geofencing and Location Tracking: Location tracking is useful for turning automatic location tracking on and off and setting the location tracking interval. Users will not be able to change these settings once the configuration policy is associated.

Geofencing is used to create a virtual fence on the map when devices exit the fence they will be marked as non-compliant and the admins will be notified. One of the many high-security Hexnode features.

Android Enterprise Compliance: This policy can be used to deactivate the Android Enterprise container on non-compliance. The deactivation time can be set for securing corporate data.

Other key features

Apps: The apps tab has everything related to applications. You can add enterprise apps and push them to the devices directly or via policies. App catalogs, app grouping, store layouts can be configured here.

You can turn websites into web apps and push them to the devices. Customizing apps, creating file shortcuts for video and pdf files, app management, app configurations, app permissions, and OEMConfig capabilities can be created and modified here.

Admin Settings and Reports: In addition to all the specific features Hexnode’s common alert and management features are also available for Seuic devices.

Inactivity settings to mark devices as inactive after a specified period. Scheduling device scans at regular intervals. Added compliance setting like device encryption, device inactivity, MDM app removal from the device, battery level alerts and notifications, etc.

Action and compliance notifications can be enabled/disabled to notify the admins or users as the case may be. A detailed report section shows a list of device, user, compliance, location, data management, application, and audit reports. These reports can be filtered and viewed. They can also be scheduled and exported as a CSV or PDF file.

How to manage seuic handheld devices using hexnode mdm

How to manage Seuic handheld devices using Hexnode MDM

How to manage Seuic handheld devices using Hexnode’s OEMConfig capabilities?

To access the OEMConfig set of features for Seuic handheld devices

Step 1: Go to the Apps tab on your Hexnode portal

Step 2: Select Add apps > Managed Google Apps

Step 3: Search for Seuic OEMConfig application and Approve it

Step 4: Go to policies > New policy > New blank policy > Android > App configurations > Configure > Add new configuration > Select the Seuic OEMConfig app

Selecting the application will show you the list of all available device features that can be managed on Seuic handheld devices using OEMConfig.

Select the management options for the required features and save the policy. Assign this policy to the required Seuic devices for management.

Seuic’s OEMConfig capabilities with Hexnode MDM

Device Settings

Sound Play: Enable or disable the sound play option

Play Scan LED: Enable or disable the plan scan LED option

Viberate: Enable or disable device vibration

Append: Enable or disable the append option

Auto Clear: Enable or disable the auto clear option

Booted start: Enable or disable the booted start option

Show Type: Enable or disable the type show option

Filter invisible chars: Enable or disable the filtering on invisible charachters

Convert Invisible chars: Enable or disable the conversion of invisible charachters

Filter Prefix/Suffix Blank: Enable or disable the option to filter the prefix/suffix blank

Set BlueTooth Setting: Default value is true(Turn on)

Enable BlueTooth Setting: Whether the users are allowed to set the BlueTooth Setting. Default Value is true (Allowed)

Set Airplane Mode: Turn On/Off Airplane Mode. Default value is false(Turn off)

Enable Airplane Mode Setting: Whether the users are allowed to set the Airplane Mode. Default Value is true (Allowed)

Enable Country Code Setting: Whether the users are allowed to set the country code. Default Value is true (Allowed)

Set Country Code: Default value is USA

Enable Frequency Band Setting: Whether the users are allowed to set the frequency band. Default Value is true (Allowed)

Set Frequency Band: Default value is Automatic

Enable Roam Delta Setting: Whether the users are allowed to set the roam delta. Default Value is true (Allowed)

Set Roam Delta: Default value is 5dBm

Enable High Density Environment Setting: Whether the users are allowed to set the high density environment. Default Value is true (Allowed)

Set High Density Environment: Default value is false

Enable Speed Up Roaming Time Setting: Whether the users are allowed to set the speed up roaming time. Default Value is true (Allowed)

Set Speed Up Roaming Time: Default value is false

Enable AGC MODE Setting: Whether the users are allowed to set the agc mode. Default Value is true (Allowed)

Set AGC MODE: Default value is MODE OFF

Enable SSID Filter Rules Setting: Whether the users are allowed to set the ssid filter rules. Default Value is true (Allowed)

Set SSID Filter Rules: Default value is No Filter Control

Enable White/Black List SSID Config Setting: Whether the users are allowed to set the White/Black List SSID Config. Default Value is true (Allowed)

Add White List SSID Config: Note! Input all the configs you want to add, but the configs should be divided by ,!

Remove White List SSID Config: Note! Input all the configs you want to remove, but the configs should be divided by ,!

Clear White List SSID Config: Note! Default value is false! If it is true, all the white list SSID Configs will be cleaned include the Configs you input above!

Add Black List SSID Config: Note! Input all the configs you want to remove, but the configs should be divided by ,!

Remove Black List SSID Config: Note! Input all the configs you want to remove, but the configs should be divided by ,!

Clear White List SSID Config: Note! Default value is false! If it is true, all the black list SSID Configs will be cleaned include the Configs you input above!

Enable Power Save Mode Setting: Whether the users are allowed to set the Power Save Mode. Default Value is true (Allowed)

Set Power Save Mode: Default value is PowerSave

Enable Data Rate Setting: Whether the users are allowed to set the Data Rate. Default Value is true (Allowed)

Set Data Rate: Default value is Data Rate AUTO

Enable PHY MODE Setting: Whether the users are allowed to set the PHY MODE. Default Value is true (Allowed)

Set PHY MODE: Default value is 802.11 AUTO

Enable Roaming Trigger Setting: Whether the users are allowed to set the Roaming Trigger. Default Value is true (Allowed)

Set Roaming Trigger: Default value is -65dBm

Allow Unsecure Wifi: Whether the users are allowed to set the Unsecure Wifi. Default Value is true (Allowed)

Allow Auto-Connect To Wifi: Whether the users are allowed to set the Auto-Connect To Wifi. Default Value is true (Allowed)

Allow Wifi Profiles: Whether the users are allowed to set the Wifi Profiles. Default Value is false (Not Allowed)

Set Wifi Settings: Default Value is true

Enable Wifi Settings: Whether the users are allowed to set the Wifi Settings. Default Value is true (Allowed)

Set Sync Frequency: Set the NTP Server Sync Interval.Default Value is 1 week

Force Reboot Device For NTP Server Setting: Whether the device should be reboot for the NTP Server Changed. Default Value is true (Reboot)

Set the NTP Server: Default value is 2.android.pool.ntp.org

Enable the NTP Server Setting: Whether the users are allowed to set the NTP Server. Default Value is true (Allowed)

Set Automatic Date & Time: Default value is true

Enable Automatic Date & Time Setting: Whether the users are allowed to set the Automatic Date & Time. Default Value is true (Allowed)

Set Select Time Zone: Note! Select Time Zone only works when Automatic Time Zone is false!

Enable Select Time Zone Setting: Whether the users are allowed to set the Select Time Zone. Default Value is true (Allowed)

Set Automatic Time Zone: Default value is true

Enable Automatic Time Zone Setting: Whether the users are allowed to set the Automatic Time Zone. Default Value is true (Allowed)

Secure Start-up: Whether the users are allowed to set the Secure Start-up.Default value is true (Allowed)

Lock Screen Setting: Default value is 5 seconds

Allow Lock Screen Setting: Whether the users are allowed to set the Lock Screen Setting.Default value is true (Allowed)

Set Device Font Size: Default value is Default

Enable Device Font Size Setting: Whether the users are allowed to set the Device Font Size. Default Value is true (Allowed)

Set Display Size: Default value is Default

Enable Display Size Setting: Whether the users are allowed to set the Display Size. Default Value is true (Allowed)

Set Stay Awake: Default value is false

Enable Stay Awake Setting: Whether the users are allowed to set the Stay Awake. Default Value is true (Allowed) for the Seuic handheld device

Set Auto-Rotate Screen: Default value is true (true means auto-rotation, false means locked)

Enable Auto-Rotate Screen Setting: Whether the users are allowed to set the Auto-Rotate Screen. Default Value is true (Allowed)

Set Screen Timeout: Default value is 1 minute

Enable Screen Timeout Setting: Whether the users are allowed to set the Screen Timeout. Default Value is true (Allowed)

Allow Background Data: Whether the users are allowed to set the Background Data. Default Value is true (Allowed)

Set Develop Options: Default value is true

Enable Develop Options Setting: Whether the users are allowed to set the Develop Options. Default Value is true (Allowed)

Allow Setting Changes: Whether the users are allowed to set the Setting. Default Value is true (Allowed)

Allow USB Host Storage: Whether the user is allowed to set the USB Host Storage. Default Value is false (Disallow)

Allow SD Card Write: Whether the user is allowed to set the SD Card Write. Default Value is false (Disallow)

Allow SD Card Move: Whether the user is allowed to set the SD Card Move. Default Value is false (Disallow)

Set Power Saving Mode: Default Value is false

Enable Power Saving Mode Setting: Whether the users are allowed to set the Power Saving Mode. Default Value is true (Allowed)

Set Storage Manager Remotely: Default value is false

Enable Storage Manager Setting Remotely: Whether the users are allowed to set the Storage Manager Remotely. Default Value is true (Allowed)

Set Do Not Disturb: Default value is false

Enable Do Not Disturb Setting: Whether the users are allowed to set the Do Not Disturb. Default Value is true (Allowed)

Alarm volume: Default value is 4. The range of alarm volume is from 0 to 7 and has to be an integer

Ring volume: Default value is 4. The range of ring volume is from 0 to 7 and has to be an integer

Media volume: Default value is 8. The range of media volume is from 0 to 15 and has to be an integer

Block Users From Adding Any Accounts: Default value is true(unblocked)

Set Magnify With Triple-Tap: Default value is false

Enable Magnify With Triple-Tap Setting: Whether the users are allowed to set the Magnify With Triple-Tap. Default Value is true (Allowed)

Allow USB Tethering: Whether the users are allowed to set the USB Tethering. Default Value is true (Allowed)

Reboot Immediately: Whether to reboot the device Reboot immediately. Default Value is true (Immediately)

Additional Device Settings

Stop Scan On Up: Enable or disable the scan of on up stop

Open Scan Statistics: Enable or disable the scan statics

Loop Scan: Enable or disable the loop scan

Interval: Enter the interval for the loop scan

Suffix: Enter the suffix for the loop scan

Prefix: Enter the prefix for the loop scan

End Char: Select the ending key for the scan

Code Charset: Select the code character set

Barcode send mode: Select the type of barcode send mode

End Char On Emu: Enable or disable end char on emu

Broadcast Barcode Action: Enter the broadcast barcode action

Broadcast Barcode Key: Enter the broadcast barcode key

Broadcast Start Scan: Enter the broadcast start scan

Broadcast Stop Scan: Enter the broadcast stop scan

Add Enter Event: Enable or disable the addition of enter event

Security level(1~3): Select the security level from 1-3

Lighting: Select the type of lighting

Continuous Scan: Enable or disable continuous scan

Advance Device Settings

Exposure Level: Select the exposure level for the device

IllumPowerLevel: Select the illum power level for the device

GS1Ai Separator: Enable or disable GS1Ai separator

PickList Mode: Enable or disable the pick list mode for the device

Inverse mode: Enable or disable the inverse mode for the device

Code 128: Enable or disable the code 128 for the device

Minimum length(0~80): Set the minimum length

Maximum length(0~80): Set the maximum length

ISBT 128: Enable or disable ISBT 128

GS1 128: Enable or disable GS1 128

magin length level: Set the margin level

UPC-A: Enable or disable UPC-A

UPC-E: Enable or disable UPC-E

UPC-E1: Enable or disable UPC-E1

EAN-8: Enable or disable EAN-8

EAN-13: Enable or disable EAN-13

Transfer UPC-A Identifying Code: Enable or disable the transfer of UPC-A identifying code

Transfer UPC-E Identifying Code: Enable or disable the transfer of UPC-E identifying code

EAN13 check send: Enable or disable EAN-13 check send

EAN8 check send: Enable or disable EAN-8 check send

UPC-A prefixing: Select whether to add just the system code or the system code and the country code

UPC-E prefixing: Select whether to add just the system code or the system code and the country code

UPCE Expanded: Enable or disable UPCE expanded

UPC-A 2 digit add on: Enable or disable UPC-A 2 digit add on

UPC-A 5 digit add on: Enable or disable UPC-A 5 digit add on

UPC-E 2 digit add on: Enable or disable UPC-E 2 digit add on

UPC-E 5 digit add on: Enable or disable UPC-E 5 digit add on

EAN13 2 digit add on: Enable or disable EAN-13 2 digit add on

EAN13 5 digit add on: Enable or disable EAN-13 5 digit add on

EAN8 2 digit add on: Enable or disable EAN-8 2 digit add on

EAN8 5 digit add on: Enable or disable EAN-8 5 digit add on

Code 39: Enable or disable code 39

Code 39 FULL ASCII: Enable or disable code 39 full ascii

Minimum length(0~48): Set the minimum length for code 39

Maximum length(0~48): Set the maximum length for code 39

Code 39 Start/End: Enable or disable the start oof code 39

Code 93: Enable or disable code 93

Minimum length(0~80): Set the minimum length for code 93

Maximum length(0~80): Set the maximum length for code 93

Code 11: Enable or disable code 11

Minimum length(1~80): Set the minimum length for code 11

Maximum length(1~80) : Set the maximum length for code 11

Transmission codes: Select the criteria for transmission codes

Interleaved 2 of 5: Enable or disable interleaved 2 of 5

Minimum length(2~80): Set the minimum length

Maximum length(2~80): Set the maximum length

Codabar: Enable or disable codabar

Minimum length(2~60): Set the minimum length for codabar

Maximum length(2~60): Set the maximum length for codabar

Codabar Start/Stop Code Send: Enable or disable the codabar stop code send

MSI: Enable or disable MSI

Minimum length(4~48): Set the minimum length for MSI

Maximum length(4~48): Set the maximum length for MSI

RSS-14: Enable or disable RSS-14

QR Code: Enable or disable QR code

Minimum length(1~7089): Set the minimum length for QR code

Maximum length(1~7089): Set the maximum length for QR code

QR Inverse: Enable or disable QR inverse code

MicroQR: Enable or disable MicroQR

QR Mirror: Enable or disable QR mirror

MicroQRInverse: Enable or disable micro QR inverse

Data Matrix: Enable or disable data matrix on the device

Minimum length(1~3166): Set the minimum length for data matrix

Maximum length(1~3166): Set the maximum length for the data matrix

China Post: Enable or disable china post

Minimum length(4~80): Set the minimum length for china post

Maximum length(4~80): Set the maximum length for china post

Matrix 2 of 5: Enable or disable matrix 2 of 5

Minimum length(4~80): Set the minimum length

Maximum length(4~80): Set the maximum length

Australian Post: Enable or disable Australian post

Japanese Post: Enable or disable Japanese post

Planet Code: Enable or disable Planet code

Postnet: Enable or disable postnet

Maximum length(1~300): Set the maximum length for postnet

Minimum length(1~300): Set the minimum length for postnet

EAN UCC Composite: Enable or disable EAN UCC composite

UPC/EAN Composite: Enable or disable UPC/EAN composite

Maximum length(1~2750): Set the maximum length

Minimum length(1~2750): Set the minimum length

PDF417: Enable or disable PDF417

Maximum length(1~2750): Set the maximum length for PDF417

Minimum length(1~2750): Set the minimum length for PDF417

MicroPDF417: Enable or disable MicroPDF417

Maximum length(1~150): Set the maximum length for microPDF417

MaxiCode: Enable or disable maxicode

Maximum length(1~3832): Set the maximum length for maxicode

Minimum length(1~3832): Set the minimum length for maxicode

Aztec: Enable or disable Aztec

Maximum length(0~2048): Set the maximum length for aztec

Minimum length(0~2048): Set the minimum length for aztec

Codablock F: Enable or disable codablockF

Maximum length(1~60): Set the maximum length for codablockF

Minimum length(1~60): Set the minimum length for codablockF

Telepen: Enable or disable Telepen

Template selection: Select the type of template

OCR: Enable or diable OCR

Grid Matrix: Enbale or disable grid matrix

Exposure Level: Select the exposure level for the device

IllumPowerLevel: Select the illum power level for the device

GS1Ai Separator: Enable or disable GS1Ai separator

PickList Mode: Enable or disable the pick list mode for the device

Inverse mode: Enable or disable the inverse mode for the device

Code 128: Enable or disable the code 128 for the device

Minimum length(0~80): Set the minimum length

Maximum length(0~80): Set the maximum length

ISBT 128: Enable or disable ISBT 128

GS1 128: Enable or disable GS1 128

magin length level: Set the margin level

UPC-A: Enable or disable UPC-A

UPC-E: Enable or disable UPC-E

UPC-E1: Enable or disable UPC-E1

EAN-8: Enable or disable EAN-8

EAN-13: Enable or disable EAN-13

Transfer UPC-A Identifying Code: Enable or disable the transfer of UPC-A identifying code

Transfer UPC-E Identifying Code: Enable or disable the transfer of UPC-E identifying code

EAN13 check send: Enable or disable EAN-13 check send

EAN8 check send: Enable or disable EAN-8 check send

UPC-A prefixing: Select whether to add just the system code or the system code and the country code

UPC-E prefixing: Select whether to add just the system code or the system code and the country code

UPCE Expanded: Enable or disable UPCE expanded

UPC-A 2 digit add on: Enable or disable UPC-A 2 digit add on

UPC-A 5 digit add on: Enable or disable UPC-A 5 digit add on

UPC-E 2 digit add on: Enable or disable UPC-E 2 digit add on

UPC-E 5 digit add on: Enable or disable UPC-E 5 digit add on

EAN13 2 digit add on: Enable or disable EAN-13 2 digit add on

EAN13 5 digit add on: Enable or disable EAN-13 5 digit add on

EAN8 2 digit add on: Enable or disable EAN-8 2 digit add on

EAN8 5 digit add on: Enable or disable EAN-8 5 digit add on

Code 39: Enable or disable code 39

Code 39 FULL ASCII: Enable or disable code 39 full ascii

Minimum length(0~48): Set the minimum length for code 39

Maximum length(0~48): Set the maximum length for code 39

Code 39 Start/End: Enable or disable the start oof code 39

Code 93: Enable or disable code 93

Minimum length(0~80): Set the minimum length for code 93

Maximum length(0~80): Set the maximum length for code 93

Code 11: Enable or disable code 11

Minimum length(1~80): Set the minimum length for code 11

Maximum length(1~80) : Set the maximum length for code 11

Transmission codes: Select the criteria for transmission codes

Interleaved 2 of 5: Enable or disable interleaved 2 of 5

Minimum length(2~80): Set the minimum length

Maximum length(2~80): Set the maximum length

Codabar: Enable or disable codabar

Minimum length(2~60): Set the minimum length for codabar

Maximum length(2~60): Set the maximum length for codabar

Codabar Start/Stop Code Send: Enable or disable the codabar stop code send

MSI: Enable or disable MSI

Minimum length(4~48): Set the minimum length for MSI

Maximum length(4~48): Set the maximum length for MSI

RSS-14: Enable or disable RSS-14

QR Code: Enable or disable QR code

Minimum length(1~7089): Set the minimum length for QR code

Maximum length(1~7089): Set the maximum length for QR code

QR Inverse: Enable or disable QR inverse code

MicroQR: Enable or disable MicroQR

QR Mirror: Enable or disable QR mirror

MicroQRInverse: Enable or disable micro QR inverse

Data Matrix: Enable or disable data matrix on the device

Minimum length(1~3166): Set the minimum length for data matrix

Maximum length(1~3166): Set the maximum length for the data matrix

China Post: Enable or disable china post

Minimum length(4~80): Set the minimum length for china post for the seuic handheld device

Maximum length(4~80): Set the maximum length for china post

Matrix 2 of 5: Enable or disable matrix 2 of 5

Minimum length(4~80): Set the minimum length

Maximum length(4~80): Set the maximum length

Australian Post: Enable or disable Australian post

Japanese Post: Enable or disable Japanese post

Planet Code: Enable or disable Planet code

Postnet: Enable or disable postnet

Maximum length(1~300): Set the maximum length for postnet

Minimum length(1~300): Set the minimum length for postnet

EAN UCC Composite: Enable or disable EAN UCC composite

UPC/EAN Composite: Enable or disable UPC/EAN composite

Maximum length(1~2750): Set the maximum length

Minimum length(1~2750): Set the minimum length

PDF417: Enable or disable PDF417

Maximum length(1~2750): Set the maximum length for PDF417

Minimum length(1~2750): Set the minimum length for PDF417

MicroPDF417: Enable or disable MicroPDF417

Maximum length(1~150): Set the maximum length for microPDF417

MaxiCode: Enable or disable maxicode

Maximum length(1~3832): Set the maximum length for maxicode

Minimum length(1~3832): Set the minimum length for maxicode

Aztec: Enable or disable Aztec

Maximum length(0~2048): Set the maximum length for aztec

Minimum length(0~2048): Set the minimum length for aztec

Codablock F: Enable or disable codablockF

Maximum length(1~60): Set the maximum length for codablockF

Minimum length(1~60): Set the minimum length for codablockF

Telepen: Enable or disable Telepen

Note:

It is highly recommendable to use the native policies wherever possible as the OEMConfig features are still relatively new. The introduction of OEMConfig has opened up a new set of possibilities which will be added to in the future and the existing features are expected to get more fine-tuned.

Seuic currently focuses on three major product lines of industrial-grade mobile terminal, visual identity products and UHF RFID products and has launched multi modal RFID products in the past year.

A dedicated device management service like Hexnode MDM can assist such devices to maximize productivity at any workplace.

Jayden Traoré

Product Evangelist @ Hexnode. Sometimes, I have the feeling I live in a story: a magnificent story written by a mediocre writer living off coffee and technology.

  •
  •
  •
  •
  •

Leave a Comment

Your email address will not be published. Required fields are marked *
